| 起源の場所: | 中国 |
| ブランド名: | RESUN |
| 証明: | FCC Part 15 Class B; UL1741,UL1741SA&SB all options, UL1699B, CSA -C22.2 NO.107.1-01,RSD(NEC690.5,11,12) |
| モデル番号: | R-16KUS |
| Model | RO-10KUS |
|---|---|
| Rated Output Power | 10000W |
| Max. Peak Power | 1.5 times rated power @10 S; 2 times rated power @0.5 S |
| Rated Output Voltage | 120/240Vac (Split-phase); 120/208V (Three-phase) ✓ |
| Max. Continuous Output Current | @240V 41.7A @208V 48.1A |
| Load Motor Capacity | 6HP |
| Locked Rotor Amps (LRA) | 123A (Ipeak) |
| Rated AC Frequency | 50/60Hz ✓ |
| Waveform | Pure Sine Wave |
| Parallel Capacity | 1 to 6 units (2 or more units can form a three-phase output) |
| Battery Type | Li-ion / Lead-Acid / User Defined ✓ |
|---|---|
| Rated Battery Voltage | 48Vdc |
| Battery Voltage Range | 40 ~ 60Vdc ✓ |
| Max. Grid Charging Current | 200A ✓ |
| Max. Generator Charging Current | 90A ✓ |
| Max. Hybrid Charging Current | 240A ✓ |
| No. of MPPT Trackers | 2 |
|---|---|
| Max. PV Array Power | 7500W+7500W |
| Max. PV Input Current | 32A+32A |
| Short-Circuit Current Isc | 40A+40A |
| Max. Open Circuit Voltage | 550Vdc/550Vdc |
| MPPT Voltage Range | 125 ~ 450Vdc/125 ~ 450Vdc |
| Input Voltage Range | 90 ~ 140Vac |
|---|---|
| Input Frequency Range | 50Hz/60Hz |
| Continuous Grid Pass through Current | 200A |
| MPPT Tracking Efficiency | 99.9% |
|---|---|
| Max. Efficiency | 97.5% |
| CEC Efficiency | 96.5% |
| Communication Port | RS485 / CAN / USB / Dry contact |
|---|---|
| External Modules | Wi-Fi / GPRS (Optional) |
| Dimensions | 840*440*260mm |
|---|---|
| Weight | 48kg |
| Protection Degree | IP65 |
| Operating Temperature Range | -25~60℃, >45℃ derated |
| Noise | <60dB |
| Self-consumption | <100W |
| Cooling Method | Heat sink + intelligent fan cooling |
| Safety Standards | UL1741&IEEE1547.1-2020, CEC, RULE 21, HECO |
|---|---|
| EMC | FCC 15 class B |
| RoHS | Yes |
